Note: Link labels A-D refer to S4148F switch ports, while link labels E-H refer to S4248FB switch ports.
The point-to-point IP addresses used in this guide are shown in Figure 11:
Rack 1
Rack 2
Spine 1
Spine 2
Leaf 4Leaf 3
Leaf 2
Leaf 1
VLTi
VLTi
A B C D E F G H
Point-to-point IP addresses
