The following formulae is used used in calculating the underutilization value of a server,
Servers with an average utilization of less than or equal to <X>
, where <X> represents a utilization percentage. The range is between 80% to 20%, by default the value is set to 15.
Servers with <Y> percentile utilization being less than or equal to <X>.
, where <Y> is the percentile. The range is between 0% to 20%, by default the value is set to 95.
Conguring underutilized servers settings
OMPC enables you to view the underutilized servers based on the power consumption.
1 In the left pane, click Analysis > Underutilized Servers and then click .
2 Enter a value in Power Utilization (X) text box and Percentile Utilization (Y) text box.
NOTE: The range for Power Utilization is 0–20. By default, the value is set to 15.
NOTE: The range for Percentile Utilization is 80–100. By default, the value is set to 95.
3 Click Save.
Power Analysis
OMPC helps you in monitoring and managing power in a data center. The observed monitoring data is helpful in planning capacity
expansion, placement suggestions.
In the left pane, click Analysis > Power Analysis. The Power Analysis screen is displayed. On this screen, you can:
• Perform data center capacity expansion planning
• Analyze and view the placement suggestions
• Analyze and view power and space gains from underutilized servers
Analyzing capacity expansion
1 In the left pane, click Analysis and then click Power Analysis.
The Power & Space Analysis page is displayed.
2 In the Capacity Planning tab, select applicable check box against the device group.
3 Select the required server model for analysis from the Select Server Model section.
Provide the number of servers and the priority of those servers in the respective elds.
4 Click Analyze to analyze the capacity for selected servers.
You can view the details of the analysis in Resource Availability section.
You can also export the report to the required location on the system.
Viewing placement suggestions
1 In the left pane, click Analysis and then click Power Analysis.
The Power & Space Analysis page is displayed.
2 In the Placement Suggestions Based on Available Power and Space section, click Launch.
Placement Suggestion window is displayed.
