Temperature Monitoring

OpenManage Power Center enables monitoring of the current and historical server inlet temperature of the data centers in Power Center.

This can help you understand the temperature status and identify hot spots in the data center.

You can monitor the temperature status at dierent device/group levels. You can congure the temperature monitoring settings to meet

your monitoring needs, and you can print the temperature status graph.

Topics:

• Temperature Monitoring Level

• Viewing Temperature Details

• Viewing a temperature history graph

• Monitoring the Temperature of the Chassis/Blade Server

• Applying circuit breaker limits to chassis

• Monitoring the Temperature of Devices/Groups

Temperature Monitoring Level

Power Center provides temperature monitoring at the following levels:

• Device level — You can monitor temperature-related metrics for devices.

• Physical group level — You can monitor temperature-related metrics at the physical group level (data center, room, aisle, chassis

modular).

• Logical group level — You can monitor temperature-related metrics at the logical group level.

Viewing Temperature Details

Click Devices in the left navigation pane, then select the Managed Groups tab. Click the icon for the group or device, then refer to the

Details section of the screen.

Click View History under the Present Power heading to access the Temperature Details graph. By default, the Temperature Details graph

displays the temperature details for the previous hour.

Temperature Details for the Current Time Window

You can view temperature details for the current time window by clicking a time window tab. The following table describes the time

windows and their associated intervals:

Temperature Monitoring 81
