Power Monitoring
Power Center enables the monitoring of current or historical power-related metrics (for example, power consumption or cost). This can
help you understand the power status in the data center and plan for additional power infrastructure, cooling, and facility needs.
You can monitor power at dierent device and/or group levels. You can congure power monitoring settings to meet your monitoring
needs, and you can print the power status graph.
Topics:
• Power monitoring levels
• Power thresholds
• Viewing power details
• Viewing Energy Consumption
• Viewing a power history graph
• Viewing system airow graph
• Monitoring PDU
• Monitoring UPS Power
Power monitoring levels
OpenManage Power Center provides power monitoring at the following levels for groups:
• Rack
• Aisle
• Room
• Data center
• Custom
Power thresholds
It is useful to monitor thresholds when you want to be notied when the power of a group and/or device exceeds the set limits.
1 In the left pane, Click Devices.
2 From the Managed Groups tab, select the group or device for which you want to set the threshold.
3 In the details section of the screen, click Thresholds.
4 Under Power Alert Thresholds (W), enter values in the Upper Warning and Upper Critical text boxes.
When the power exceeds the upper warning value, a warning-level event alert is sent. When the power exceeds the upper critical
value, a critical-level event alert is sent.
5 Click Save.
For more information on conguring the device/group range and sampling interval, see Monitoring Settings.
