Moving a virtual machine group
After creating a virtual machine group, you can move the group to another existing virtual machine group.
1 In the left pane, click Virtual Machines > VM Groups.
2 Select Move to move a VM group to another VM group.
The current VM group is displayed as Current Entity.
3 The available VM groups to which you can move is listed as Move to. Choose the VM group to which you want to move.
4 Click Save.
The VM group is moved to the selected group.
Viewing a virtual machine power history graph
OpenManage Power Center provides a visual representation of the power history of a virtual machine or a group of virtual machines.
1 In the left pane, click Virtual Machines > All Virtual Machines or Virtual Machines > Virtual Machine Groups.
2 From the list of devices, select a virtual machine or a group of virtual machine.
3 In the Details tab, click Power History.
The Power History-<VM Name> page is displayed.
4 Select the time period and attributes displayed:
a To select the time period represented in the graph, click the buttons along the top of the graph.
b To add or delete attributes, select from the listed options; click the option to toggle its addition or removal from the graph:
• Estimated VM Power
• Hypervisor Power
NOTE
: If you select a group, only Estimated VM Group Power attribute is displayed.
NOTE: To view specic numbers related to each attribute displayed in any section of the graph, move the pointer over
the graph.
5 To move along the data stream over time, click the navigation arrows below the graph.
Viewing a virtual machine power distribution graph
OpenManage Power Center provides a visual representation of the power distribution of a group of virtual machines.
1 In the left pane, click Virtual Machines > Virtual Machine Groups.
2 From the list of devices select a group of virtual machine.
3 In the Details tab, click Power Distribution.
The Estimated VM Power for Group:<Virtual Machine Name> page is displayed.
4 To move along the data stream over time, click the navigation arrows below the graph.
Deleting a VM group
After creating a virtual machine group, you can delete that group.
1 In the left pane, click Virtual Machines > VM Groups.
2 Select the VM group that you want to delete an click Delete.
3 A message asking for a conrmation to delete the VM group is displayed. Click Yes.
The selected VM group is deleted successfully and the virtual machines associated with the VM group is disassociated.
