Users Guide

The Add to Rack Slots wizard is displayed.
5 Select the check boxes next to the devices you want to add to the rack and click Next.
6 From the Select drop-down list next to the devices you want to add to the rack, select the slots into which you want to place the
devices.
7 Click Finish to return to the Manage Rack screen and review your changes.
Adding an associated device to a rack
1
In the left pane, click Devices > Managed Groups.
2 From the list of devices select a rack device.
3 In the task menu, click Manage Rack > Associated Devices > Add To Rack.
The Associate a Device with a Rack window is displayed.
4 Select the check box next to the device that you want to associate with the rack.
5 Click Finish to return to the Manage Rack screen and review your changes, or click Cancel to return to the previous screen.
Editing a rack-associated device
1 In the left pane, click Devices > Managed Groups.
2 From the list of devices select a rack device.
3 In the task menu, click Manage Rack > Associated Devices > Add To Rack.
4 Select the check box next to the device that you want to associate with the rack.
5 Click Finish to return to the Manage Rack screen.
6 From the list of devices, select the device you want to edit, and click Edit.
7 Make the desired changes.
8 Click Finish to return to the Manage Rack screen and review your changes, or click Cancel to return to the previous screen.
Rearranging devices in a rack
1 In the left pane, click Devices > Managed Groups.
2 From the list of devices select a rack device.
3 In the task menu, click Manage Rack.
The Manage Rack window is displayed. By default, the Rack Contents tab is displayed.
4 In the Rack Contents tab, click Rearrange Rack.
The Move In Rack window is displayed with the list of slotted devices.
5 From the New Slot drop-down list next to the devices you want rearrange, select the slots into which you want to move the devices.
NOTE
: Starting OMPC 4.0, you can add devices with size up to 42U.
6 Click Finish to return to the Manage Rack screen and review your changes.
Removing a rack-associated device
1 In the left pane, click Devices > Managed Groups.
2 From the list of devices select a rack device.
3 In the task menu, click Manage Rack > Associated Devices.
4 From the list of devices, select the device you want to remove.
5 In the task menu, click Remove.
The following message is displayed: The device will not be deleted, but will remain in the Devices List.
70
Device Management
