subordinate) or not. Adding a daisy chained PDU to a rack automatically associates the subordinate PDUs to that particular rack. However,
you can also associate or disassociate a subordinate PDU from the master PDU individually.
NOTE: If you disassociate a subordinate PDU from the master PDU, it is removed only from that particular daisy chain
arrangement.
NOTE: Deleting a master PDU does not delete the associated subordinate PDUs.
Viewing chained PDUs
1 In the left pane, click Devices > All Devices.
2 From the list of devices, select a PDU device.
3 If the selected PDU is a Master PDU, Associate Subordinate PDU option is displayed.
4 Click on the Associate Subordinate PDU option to view the associated subordinate PDU.
The sequence of the associated PDUs, PDU name, PDU model, Service tag, and the time of discovery is displayed.
5 If the selected PDU is a subordinate PDU, Associate Master PDU option is displayed.
6 Click on the Associate Master PDU option to view the associated master PDU.
The PDU name, PDU model, Service tag, and the time of discovery is displayed.
Managing groups
OpenManage Power Center enables you to create groups for organizing devices, so that you can manage them more eciently. The groups
can be of the following types:
• Datacenter
• Room
• Aisle
• Rack
• Custom
In the left pane, click Devices > Managed Groups. In this tab, you can:
• View details of a specic device group
• Add groups
• Edit groups
• Delete groups
• Refresh the list of device groups
• Move devices from one group to another
• Manage racks
• Enable or disable Emergency Power Reduction (EPR)
• View rack utilization graphs
Mapping Group Structure Information
OpenManage Power Center supports group structure mapping for PowerEdge rack servers and tower servers.
After you create or update the group structure, Power Center automatically updates the location information in the rmware of supported
devices using the following mapping structure:
• Data Center — Data center and room information in Power Center; format: <Data Center - Room>
