NOTE: You can select multiple protocols.
• Select the Status check box, and select device status from the drop-down list. The available options are:
• Connected
• Lost Connection
• NA
NOTE: You can select multiple status.
•
Select the Device Model check box, and choose a model from the drop-down list. The device model is the specic model
information of a device type, for example, PowerEdge M610.
NOTE: If you select both Device Type and Device Model, ensure that the device type and the device model
match. Otherwise, the results may not be displayed.
• Select the Estimated Max Power (W) check box and enter the maximum power for device. The estimated max power is
considered as the peak power consumption by a device.
6 Click Save and Run to save the lter.
OR
• Click Run Once to view a ltered list of devices.
OR
• Click Cancel to return to the All Devices tab.
You can use the saved lters later.
Editing a device
You can edit devices or device groups from the Devices screen.
1 In the left pane, click Devices.
2 Select the check box next to the device or device group that you want to edit.
3 Click Edit.
The Edit Entity screen is displayed.
4 Make the required changes.
For devices, you can edit the name of the device, device description, size of the device, and estimated maximum power. For device
groups, you can edit the group type, group name, group description, and power capacity.
NOTE
: For PDUs, you have an option to replicate the rack association relationship.
5 Click Finish to save your changes, or click Cancel to return to the Devices screen without saving your changes.
Deleting devices using a lter
You can also delete devices using the Filter feature.
1 In the left pane, click Devices.
2 In the task menu, click Filter.
The Device Filter window is displayed.
3 Select the lter by which you want to sort the devices list.
4 Select the check boxes next to the devices that you want to delete.
5 In the task menu, click Delete.
The following message is displayed.
Are you sure you want to delete the selected item(s)?
6 Click Yes to proceed with the deletion.
Device Management
65
