Adding a protocol

1 In the left pane, expand Tasks, and click Protocols.

The Protocols screen is displayed.

2 In the task menu, click Add.

The Add Protocol window is displayed.

3 In the Prole Name and Description section, enter a name and a description for the protocol.

4 In Protocol Information, select one of the following options:

• Server

• IPMI Protocol

• Redsh Protocol

• Chassis

• WS-MAN Protocol

• HTTPs Protocol

• SSH Protocol

• PDU/UPS

• SNMPv1v2c

• SNMPv3

• Hypervisor

• HTTPs Protocol

• WMI Protocol

NOTE

: By default, OpenManage Power Center uses port 8643 for power center application and port 8644 for redsh

HTTPS events. You also have the option to use a dierent port apart from the default port.

5 Click Finish.

Editing a protocol

You can edit the protocol information of a device.

1 In the left pane, expand Tasks and click Protocols.

The Protocols screen is displayed.

2 Select the check box next to the protocol prole name you want to edit.

3 In the task menu, click Edit.

The Edit Protocol window is displayed.

4 Make the required changes.

5 Click Finish to save your changes, or click Cancel to discard them.

Deleting a protocol

1 In the left pane, expand Tasks, and click Protocols.

The Protocols screen is displayed.

2 Select the check box next to the connection protocol that you want to delete.

3 In the task menu, click Delete.

The following message is displayed: Are you sure you want to delete the selected protocol(s)?

Task management
