• SSH User Name — The user name for WMI-based device communication for managing third-party enclosures. Maximum length is

255 characters.

• SSH Password — The password for SSH-based device communication. Maximum length is 255 characters.

• WMI Port — The port for WMI-based device communication. The default port is 443.

• Validate Certicate — (Optional) Enables device certicate validation.

NOTE: You can change the protocol timeout settings in the Settings > General tab.

Redsh protocol support

Starting OMPC 4.0, you can discover devices by using the Redsh protocol. The tasks that you can perform by using the Redsh protocol

depends on the roles dened by the Distributed Management Task Force (DMTF) standard, namely Administrator, Operator, and ReadOnly.

For example, with the administrator role, you have access to all the iDRAC privileges, with the ReadOnly role, you have access only to the

iDRAC login privilege. For more information on the roles and iDRAC privileges, see the iDRAC Redsh reference guide.

In OMPC, you can discover and manage devices by using multiple protocols. For example, to manage servers-you can use the IPMI or the

Redsh protocol. OMPC does not change the protocol in use for devices discovered earlier. If you want to change the protocol to manage

a device, you have to delete the device discovered using a protocol and rediscover with the other protocol.

NOTE: You cannot discover the Non-Dell servers through the Redsh protocol.

Limitations in using OMPC with Redsh protocols and devices

• You cannot discover Non-Dell servers through the Redsh protocol.

• Power capping and iDRAC location update functionality is supported only on Dell’s 14th generation of PowerEdge servers.

• CUPS metrics, CFM metrics, and subsystem power metrics information are not available on devices discovered through the Redsh

protocol.

• The following features are not supported by the Redsh protocol:

• iDRAC location update

• Calculating average power

• Power Capping

• CUPS

• Airow

• Outlet Thermal

• PEC Chassis Information—only for C6320

• Graceful shutdown and graceful restart

• The following features are not supported on iDRAC9 by the Redsh protocol:

• CUPS

• Airow

• Outlet Thermal

• Slot number in chassis—only for C6420

• Graceful shutdown and graceful restart

NOTE

: In OMPC 4.0, there are restrictions in using Redsh protocol with the lockdown feature of iDRAC enabled. For more

information, see Troubleshooting chapter.

NOTE: By default, the Redsh events are not logged into the event list. For more information, see Troubleshooting

chapter.

Task management 59
