Editing a user or group account
1 In the left pane, click Settings > Users.
2 Select the check box next to the user or group account that you want to edit, then click Edit.
The Edit a User or Group Account window is displayed.
3 Make the required changes, then click Save to save your changes, or click Cancel to discard them and return to the Users tab.
Deleting a user or group account
NOTE: You cannot delete the Power Center managed user (super user) created during installation.
1 In the left pane, click Settings > Users.
2 Select the check box next to the user or group account you want to delete.
3 Click Delete.
The following message is displayed: Are you sure you want to remove the selected item(s)?
4 Click Yes to proceed or No to return to the Users tab.
Changing a user account password
Do one of the following:
• Change the password of the current user.
a In the top right hand-side of the OpenManage Power Center screen, click the user account name with which you are currently
logged in. The Current User window is displayed.
b Enter the current password in the Current Password text box.
c Enter the new password in the New Password text box.
d Enter the new password again in the Verify Password text box to conrm.
e Click Save to apply the new password or click Cancel to discard your changes.
• Change any user or group account password on the Settings > Users screen.
1 Click Settings > Users and select the check box next to the user account whose password you want to change.
2 In the task menu, click Edit.
3 Enter the new password in the Password text box.
4 Enter the new password again in the Verify Password text box to conrm.
5 Click Save to change the password, or click Cancel to discard your changes.
Viewing current user information
You can view current user information and update the current user’s password.
To view current user information, click the login user name in the upper-right corner of the OpenManage Power Center screen, or go to
Settings > Users.
To change the current user password, see Changing A User Or Group Account Password.
