Every Power Center screen functions dierently depending on the privilege level assigned to a user account:
• Fully functional—User can view and edit all.
• Partially functional—User can partially view or edit.
• Not functional—User sees a blank page.
Global Conguration
The Global Conguration privilege enables a user to change the Power Center global conguration—for example, the sampling interval and
database settings. Users without this privilege can only view part of the Settings page, and cannot make any changes (the Edit option is
not available).
Manage Role/User
Users with the Manage Role/User privilege can:
• Create roles
• Delete roles
• Update roles
• Create users
• Delete users
• Update users
Users without this privilege can only view their own user account information and update the password.
View Device/Group
The View Device/Group privilege enables a user to view all device and group information. Users without this privilege cannot view device or
group information; they can only view the Settings page.
Users with only the View Device/Group privilege have the following restrictions:
• The Run Discovery task is not available.
• Add/Edit/Delete functionality is disabled on the Devices screen.
Manage Device/Group
The Manage Device/Group privilege enables a user to:
• Create groups
• Create a Data Center/Room/Aisle/Rack/Device
• Associate Data Center/Room/Aisle/Rack/Device/Group
• Manage a device
• Remove a device/group from the Device List
NOTE
: When you assign the
Manage Device/Group
privilege to a user, Power Center automatically assigns the
View Device/
Group
privilege to this user as well.
50 Access control
