Windows NT LAN Manager (NTLM) authentication limitation
OpenManage Power Center supports Kerberos SSO for Windows domain user authentication. To enable this feature, OpenManage Power
Center is congured to support the Windows integrated authentication option which includes two authentication mechanisms: Kerberos
and NTLM .
NTLM is not supported in OpenManage Power Center. If the client’s web browser uses NTLM to authenticate domain users for
OpenManage Power Center, there are some limitations.
The web browser displays a message box requiring a Windows user name and password.
• If you click OK after entering a user name and password, whether the information is correct or not, the OpenManage Power Center
login page is displayed and requires you may have to authenticate through the login page.
• If you click Cancel, an HTTP Status 401 failure displays, and you cannot log into Power Center.
See Troubleshooting for more information on how to resolve this issue.
Logging out
To log out of OpenManage Power Center when not logged in through Kerberos SSO, click Logout at the upper right corner of the
management console.
When logged in through Kerberos SSO, close the web browser or the OpenManage Power Center management console to log out. Clicking
Logout does not work.
Managing user roles and privileges
OpenManage Power Center supports three pre-dened roles:
• Administrator: All privileges
• Power User: All privileges except Manage role/user and Manage license
• Guest: View device/group privileges only
These pre-dened roles cannot be edited or deleted.
NOTE
: Only users with the
Role/User Management
privilege can add, edit, or delete a role or user or group account.
Adding a custom role
1 In the left pane, click Settings > Roles.
2 Click Add a Role.
The Add Role window is displayed.
3 Enter a name for the role in the Role Name text box. Ensure that the name does not exceed 50 characters.
4 Enter a description for the role in the Role Description text box. Make sure that the description does not exceed 1024 characters. This
eld is optional.
5 Under Select Privileges, select the check box next to the rights that you want to assign to the role. The available options are:
• Global Conguration
• Manage Role/User
• View Device/Group
48
Access control
