list_groups

Usage:

ompc_cli list_groups [-unique] [GROUP_PATH]

The list_groups command lists all child groups for the GROUP_PATH (immediate only). If no GROUP_PATH is supplied, the CLI lists all group

paths or all unique groups in OMPC. Properties include the fully-qualied group name, group type, and member_count. The member_count

property is the number of devices and groups immediately under the child group.

[-unique] has no impact if GROUP_PATH is provided.

If “/” is provided as GROUP_PATH, then the CLI lists the groups at root level.

A group might have multiple fully-qualied group names. When [-unique] is provided, the CLI lists all unique groups; otherwise, the CLI

lists all group paths.

Example output for list_groups:

group_name, group_type, member_count

myservers/mygroup, Room, 20

list_report_groups

Usage:

ompc_cli list_report_groups

The list_report_groups command is used to list all report groups. Each report group is output in one row containing these elds:

report_group_name, description and created_by.

list_reports

Usage:

ompc_cli list_reports [REPORT_GROUP]

The list_reports command is used to list user dened reports. REPORT_GROUP is the name of a report group. If no REPORT_GROUP

is supplied, all reports are listed. Else, only those belonging to the specied REPORT_GROUP are listed.

Each report is output in one row containing these elds: report_name, description, format, report_group_name,

created_by and status (running or not).

run_report

Usage:

ompc_cli run_report [-start_date <start_date>] [-end_date <end_date>] [-format <CSV|XML>] [-

file_name <file_name>] [-detail] REPORT_NAME

The run_report command is used to run a saved report and export the result to the console or to a le.
