Supported and unsupported devices

You can discover supported devices, and create a group structure to build out the data center. Power Center cannot discover or manage all

device types, and unsupported devices must be manually added to make the data center group structure complete.

For supported devices:

• Device types include chassis, server, UPS, and PDU.

• Set the connection protocol and credential information so that the device can communicate with Power Center.

• Perform management functions including discovery, adding to the group structure, monitoring power and temperature, applying power

management policies, and sending events.

Power Center supports up to 6000 managed devices in one data center.

Table 3. Supported devices

Category Supported Platform Validated Model

Server Dell

• PowerEdge R310 Server

• PowerEdge R410 Server

• PowerEdge R515 Server

• PowerEdge R610 Server

• PowerEdge R710 Server

• PowerEdge R715 Server

• PowerEdge R810 Server

• PowerEdge R815 Server

• PowerEdge R910 Server

• PowerEdge M610 Server

• PowerEdge M610x Server

• PowerEdge M710 Server

• PowerEdge M710HD Server

• PowerEdge M910 Server

• PowerEdge T610 Server

• PowerEdge T710 Server

• PowerEdge FM120 Server

• PowerEdge R320 Server

• PowerEdge R420 Server

• PowerEdge R520 Server

• PowerEdge R620 Server

• PowerEdge R720 Server

• PowerEdge R720xd Server

• PowerEdge R820 Server

• PowerEdge R920 Server

• PowerEdge M420 Server

• PowerEdge M620 Server

• PowerEdge M520 Server

• PowerEdge T320 Server

• PowerEdge T420 Server

• PowerEdge T620 Server

• PowerEdge R330 Server

• PowerEdge R430 Server
