Upgrade failure recovery on Microsoft Windows
operating system
Check OMPC status
If the installer process is stopped or server is switched o during upgrade, the upgrade fails. Follow the steps to troubleshoot the upgrade
failure scenario:
1 Run wmic product where name='Dell OpenManage Power Center' get version command on the windows command line interface to
get the current version OMPC.
2 If the OMPC old version is displayed, for example 3.1.0.XXXX, it means OMPC upgrade operation has not been started, see Recover
OMPC section.
3 If the OMPC new version is displayed, for example “3.2.0.XXXX”, it means OMPC upgrade has been started, see Check OMPC
database service status
section.
4 If neither old nor new version is displayed, see Rollback to previous OMPC version section.
5 See OMPC database upgrade status to view the upgrade status.
Recover OMPC
1 Check All OMPC services, if one or more services does not exist, see Recover OMPC section. If not, proceed with the next step.
2 Start All OMPC services if they was not started.
NOTE
: If Dell OpenManage Power Center Database Server service cannot be started, check [DataDir]. If it has been
renamed to [DataDir]bak (for example, pgdatabak), then you may need to rename it to [DataDir] (for example, pgdata)
and restart this service again.
NOTE: If you renamed [DataDir] folder, you should give Network Service full control privilege to this folder. if the
service still could not get started, see Rollback to previous OMPC version section.
3 Remove [LocalAppData]\ompc\ompcold if it exists.
Check OMPC database service status
If OMPC database services can be started, and you can successfully login to the OMPC database dcmapp using the OMPC database
privileges , see OMPC database upgrade status to check OMPC database upgrade status. See Rollback to previous OMPC version to
recover old OMPC.
Rollback to previous OMPC version
1 Uninstall the new OMPC using msiexec /x {79427712-CD0A-4114-A571-6BCA07F2EE0A} NOWARNING=1
REMOVEINSTALLDIR=0.
A
