Software requirements

OpenManage Power Center supports the following operating systems:

• Microsoft Windows Server 2012 x64 Standard Edition

• Microsoft Windows Server 2012 x64 Data Center Edition

• Microsoft Windows Server 2012 x64 Essential Edition

• Microsoft Windows Server 2012 R2 Essentials Edition

• Microsoft Windows Server 2012 R2 Standard Edition

• Microsoft Windows Server 2012 R2 Datacenter Edition

• Microsoft Windows Server 2016 Standard Edition

• Microsoft Windows Server 2016 Data Center Edition

• Microsoft Windows 8.1 Professional

• Microsoft Windows 8.1 Enterprise

• Microsoft Windows 10 Professional

• Red Hat Enterprise Linux 6.9 x86_64

• Red Hat Enterprise Linux 7.3 x86_64

• SUSE Linux Enterprise Server 11 SP4 x86_64

• SUSE Linux Enterprise Server 12 SP2 x86_64

OpenManage Power Center supports the following web browsers:

• Google Chrome 55, 56, and 57

• Mozilla Firefox 50, 51, and 52

• Microsoft Edge

• Microsoft Internet Explorer 10 and 11

NOTE

: OMPC performs best with Google Chrome, Mozilla Firefox, or Microsoft Edge as these browsers prevent Cross-site script

(XSS) using Content Security Policy (CSP) 1.0. The CSP 1.0 is not supported on Internet Explorer 11.

The OpenManage Power Center installation includes the following major software tools:

• Oracle Java Runtime Environment (JRE) 8 Update 102

• Apache Tomcat application server 7.0.63

• PostgreSQL 9.3.14

Hardware and software requirements for devices

• Managed servers must have Integrated Dell Remote Access Controller (iDRAC) 6, 7, 8, or 9.

NOTE

: You can use OMPC on iDRAC6 for monitoring the devices; however power capping feature is not supported.

• Power Distribution Unit (PDU) and Uninterruptible Power Supply (UPS) devices must comply with the Management Information Base

(MIB) the vendor provides through SNMP interface.

• Devices must provide exclusive access for Power Center because the policies set on the devices from other management software

aect the Power Center power control function.

• The Baseboard Management Controller (BMC) user, through which Power Center communicates with devices, must be a local user

account whose roles include Administrator. The device must be congured to allow the Administrator to use at least one of the cipher

suite levels 0–3, and enable the IPMI over LAN setting.

• The WSman user, through which Power Center communicates with the chassis, must be a local user with the Administrator role. The

chassis must be congured to enable the Web Server service.
