Troubleshooting
This chapter lists some of the known issues you may encounter when working with Power Center.
Why am I being required to log in more than once by
Power Center?
Possible Cause: This occurs when one of the following elements of Kerberos SSO is not correctly congured: the Power Center server, the
web browser, or the AD domain controller conguration.
Resolution: Correctly congure your Power Center server and web browser for Kerberos SSO. For more information, see your web
browser’s Help documentation.
Why can’t I access the Power Center management
console from a Web browser, even though the Power
Center server is running normally?
Possible Cause: A proxy setting may prevent the browser from accessing the Power Center server on the network.
Resolution: Check your proxy server settings to make sure they are properly congured.
Why was I automatically logged out of Power Center?
Possible Cause: The network connection was lost.
Resolution: Check your network connection status; make sure that it is connected to the Power Center server.
Possible Cause: The console session timed out.
Resolution: Check the Settings > General > Console Sessions Timeout settings.
Possible Cause: Your user account was deleted.
Resolution: Check your user account status to make sure it was not deleted by another user with higher privileges.
Why did my connection to iDRAC6 devices
(PowerEdge Servers) fail, when the network
connection status is
Connected
?
Possible Cause: iDRAC6 devices are limited to three concurrent connection sessions, and you have reached the limit. There are various
reasons that may cause the session to be occupied for a while until it is relinquished—for example, you used incorrect credential
information to connect with iDRAC6 devices for three times or more within a short period.
