Sending test events from an IPMI device
Power Center enables you to view test events sent from an IPMI device, therefore, you can verify the event channel between the IPMI
device and Power Center server.
Before sending a test event, make sure:
• The IPMI device is added on the Devices page.
• The network connection status of the IPMI device is Connected.
• The Power Center server address is added in the event destination list of the IPMI device.
To send a test event from an IPMI device, see the following example for a PowerEdge M610 server:
1 Open the iDRAC management console of the M610, and go to the page related to SNMP trap settings.
2 Click Send next to the Power Center server address to send a test event.
3 Open the Power Center management console, and click Event Logs in the left pane.
The informative event IPMI Test appears on the Event Logs page.
NOTE: For more information on steps 1 and 2, see the IPMI device documentation.
