threshold, then Critical and Warning events are sent when the average temperature reaches 60 °C. When the average temperature returns
to 45 °C, the Critical event automatically becomes Informative. When the average temperature returns to 35 °C, the Warning event
automatically becomes Informative.
Application log events
The application log contains information about informational or unexpected events, or internal errors that occur in OpenManage Power
Center.
Table 10. Application log events
Type Severity Functional area Description
Internal Error Warning Service Power Center internal error.
Duplicated Managed Devices Warning Discovery Duplicated device identied.
Group Structure Change Policy Warning Policy A group structure has aected a policy.
Database Maintenance
Successful
Informative Service Database maintenance was successful.
Protocol Timeout Change Failed Warning Monitor The protocol timeout change failed.
Duplicate Device Deleted Informative Discovery The duplicated device has been deleted.
Email Failure Warning Event The email alert for the event has failed. SMTP or Alert
Settings might be incorrect.
Internal Database Operation
Error
Warning Service Internal database operation failed.
Discovery In Progress Warning Discovery Current round of scheduled discovery task is skipped
because a previously scheduled instance is still
underway.
Chassis Inventory In Progress Warning Discovery Current round of chassis inventory task is skipped
because a previously instance is still underway.
Re-run Running Discovery Task Warning Discovery Previous discovery task is stopped as a user has re-
run this task.
License Violation Detected Critical License License violation has been detected.
License Violation Rectied Informative License License violation has been rectied.
Policy On Non Power Capping
Device
Warning Policy The device's power capping capability is removed.
Application Logs Cleared Informative Log All application logs have been removed.
Require License For Power
Policy
Warning License Failed to set power policy due to insucient license.
Supported PDU and UPS events
Power Center supports events for dierent PDU and UPS devices. The following table lists the events that are validated by Power Center
for specic devices. There may be other events not mentioned in this table.
106
Event Management
