Type Description Severity Level
UPS Input Power Events related to power input failure in the
UPS.
Critical
UPS On Bypass Events related to on bypass in the UPS. Informative
UPS Output Power Events related to power output failure in the
UPS
Critical
UPS Overload Events related to output power load limits
and exceeded thresholds in the UPS.
Critical
UPS Shutdown The UPS has shutdown. Informative
UPS Temperature Threshold A UPS temperature threshold was
exceeded.
Critical
Custom events
Custom events that you have set up are automatically triggered when the custom condition threshold is reached.
Table 9. Power Center custom events
Type Description Severity Level
Average Inlet Temperature Average temperature is greater or less than
the average value you set in the Thresholds
Critical or Warning; depends on the
threshold type
Policy Cannot Be Maintained Policy cannot be maintained because
average power consumption of devices with
power capping capability that relate to this
policy exceed the power cap value of this
policy
Critical or Warning
Policy Return To Normal Policy can now be maintained, because
power consumption is less than the power
cap value
Informative
Power Average power consumption is greater than
the average value you set in the Thresholds.
Critical or Warning
Power Return To Normal Power consumption returned to the normal
range you set in the Thresholds
Informative
Temperature Return To Normal Temperature returned to the normal range
you set in the Thresholds
Informative
When the following changes occur, then corresponding Critical events become Informative events:
• Device/group is removed from Power Center.
• Event condition is removed from Power Center; for example, the Threshold settings.
• Event condition is updated in Power Center; for example, the Threshold settings.
• Power policy is removed or disabled.
• Policy Return To Normal event is triggered.
For example, when the Power/Temperature Return to Normal event is triggered, the corresponding Critical or Warning event becomes an
Informative event. Using the Average Inlet Temperature as an example: If you set 50 °C as the Critical threshold and 40 °C as the Warning
