Type Description Severity Level
MPCM Congure Failed Failed to set MPCM on the chassis. Warning
MPCM Not Supported The Dell chassis does not support MPCM.
Upgrading rmware on the chassis might be
required.
Warning
PDU High Load The PDU power is greater than the high load
threshold.
Warning
PDU Low Load The PDU power is lower than the low load
threshold.
Warning
PDU Outlet High Load The PDU outlet power is greater than the
high load threshold.
Warning
PDU Outlet Low Load The PDU outlet power is lower than the low
load threshold.
Warning
PDU Outlet O The PDU outlet is O. Informative
PDU Outlet On The PDU outlet is On. Informative
PDU Outlet Overload The PDU outlet is overloaded. Critical
PDU Overload The PDU is overloaded. Critical
Protocol Operation Failed Device protocol operation failed. Warning
Server Capabilities Changed The server capabilities have changed, for
example, a license change. This event is only
applicable to a device that has a policy
applied. When you see such an event, check
the policy on the device.
Warning
Unsupported Sampling Interval Cannot set sampling interval to device.
iDRAC 6 devices with a BMC rmware
version older than version 1.5 only support a
1-minute sampling interval. Use a 1-minute
sampling interval for such device, or upgrade
the BMC rmware to newer version.
Warning
UPS Battery Failed Events related to battery failure in the UPS. Critical
UPS Battery Low Events related to low battery limits and
exceeded thresholds in the UPS.
Critical
UPS Bypass Failure Events related to bypass failure in the UPS. Critical
UPS Charge Failure Events related to charge failure in the UPS. Critical
UPS Communication Lost Events related to communication lost in the
UPS.
Warning
UPS Fan Failure Events related to power fan failure in the
UPS.
Critical
104 Event Management
