• PowerEdge blade servers – Only support IPMI Processor Temperature Trip events.
• Integrated Dell Remote Access Controller (iDRAC) – Only supports the IPMI trap format. To receive events from an iDRAC device,
make sure the alert function is enabled and the IPMI trap format is selected for all Power Center-supported events in the iDRAC
management console (IPMI Power Unit, IPMI Power Supply, IPMI Processor Temperature Trip, IPMI Fan). For example, in the iDRAC7
management console, you must select IPMI trap for all PWR/PSU/CPU/Fan-related alerts.
NOTE: For more information on using the iDRAC management console, see iDRAC documentation.
Table 8. Power Center events and severity levels
Type Description Severity Level
Blades Change In Chassis Some blades in a chassis have changed; you
must manually rediscover the chassis. Power
Center detects chassis changes once every
15 minutes
Informative
Cannot Register for Events The device cannot register device events to
the Power Center server automatically.
Warning
Chassis Power Control Capabilities Changed The circuit braker power control (system
input power cap) capability on the chassis
no longer exist.
Critical
CMC SNMP Event Event received from chassis Critical or Warning
Communication with Chassis Failed Power Center lost communication with the
chassis.
Warning
Communication with Chassis Restored Power Center restored communication with
the chassis.
Informative
Communication with Device Failed Power Center lost communication with the
device.
Warning
Communication with Device Restored Power Center restored communication with
the device.
Informative
Device Hostname Changed Device hostname is changed. Informative
Entity Capabilities Changed Entity capabilities changed. Warning
Failed to Set Sampling Interval on Device Failed to set sampling interval for the device.
The sample interval might not be supported
by device.
Warning
iDRAC SNMP Event Event received from iDRAC. Critical or Warning
IPMI Fan Events related to the server fan. Critical
IPMI Power Supply Events related to the server. Critical
IPMI Power Unit Events related to the server power unit. Critical
IPMI Processor Temperature Trip Events related to the server processor
temperature trip.
Critical
IPMI Test An IPMI test event was received. Informative
