Figure 44. Adding an MX7000 Chassis using Quick Sync 2
NOTE:
You are prompted to enable access to the location and camera when you start OpenManage Mobile for the
first time after an installation or upgrade.
5. Tap Connect via Quick Sync 2, and tap Next.
A video on how to enable the bluetooth connection is displayed.
6. Tap Next.
NOTE:
You are prompted to enable access to bluetooth.
7. Select the chassis that you want to add, and tap Next. You can use the Blink LED option to identify the chassis.
8. You can authenticate the chassis in one of the following ways:
QR Scan:
a) On the credentials page, tap SCAN QR CODE.
You are prompted to provide access to the camera. The credentials are automatically populated.
b) Tap Add Device.
Position the camera to scan the QR code displayed on the LCD panel of the chassis.
NOTE:
To enter the credentials manually or by using QR scan, ensure that the Read authentication is Enabled on
the server.
Manual credentials:
a) Enter the credentials to add the chassis.
b) Enter the credentials.
c) Tap Submit.
