Users Guide

Adding multiple iDRACs using a network
This feature enables you to add multiple iDRACs using a network.
NOTE: You can add multiple iDRACs only if the username and password is the same.
To add multiple iDRACs:
1. Start OpenManage Mobile.
2. If applicable, type the OMM password and tap Login.
The OMM home page is displayed.
3. Perform one of the following:
• On the OMM home page, tap Connect
• On the OMM home page, tap View All, and tap in the upper right corner.
4. Tap Server, and tap Next.
5. Tap Connect via Network, and tap Next.
6. You can add all the iDRACs in the range by using a * for the last octet.
For example, 192.168.0. Or, you can type the start and end range of the iDRACs in the last octet and use a dash to separate it in IP/
Hostname. For example, 192.168.0.50-100.
7. Type the username, password, domain (if applicable) of the iDRAC.
8. Tap Submit.
The process of adding multiple iDRACs is initiated. You can check the status of the process in the Task Manager.
Quick Sync 2
Quick Sync 2 uses the integrated wireless capabilities of Quick Sync 2 equipped PowerEdge servers to directly manage those servers.
Quick Sync 2 uses encrypted Bluetooth Low Energy (BLE) and dedicated WiFi connections. Quick Sync 2 is activated on the server using
the connection button.
An infrastructure network uses your WiFi base station or VPN connection to communicate with the iDRAC IP-based management network
connected to the wired Ethernet port of the iDRAC. The connection uses the WS-Man protocol.
Adding an iDRAC using Quick Sync 2
1. Perform one of the following:
• On the OpenManage Mobile home page, tap Connect
•
On the OpenManage Mobile home page, tap View All, and tap in the upper right corner.
34
Managing iDRAC
