Reference Guide

},
{
"Key": "gatewayV6",
"Value": "255.255.255.0"
},
{
"Key": "SlotId=1",
"Value":
"SlotSelected=true;SlotType=3000;IPV4Address=10.27.0.1;IPV6Address=ax0"
},
{
"Key": "SlotId=2",
"Value":
"SlotSelected=true;SlotType=2000;IPV4Address=10.35.0.25;IPV6Address="
}
]
}
Table 173. Attributes
Attribute name Description
Id ID of job. The default ID for POST is 0.
JobName Name of the Quick-Deploy Job.
JobDescription Description of the Quick-Deploy Job.
Schedule The schedule to start the Job. Quick-Deploy is startnow.
State Indicates if the job is enabled or disabled.
JobType
Id ID of the job type.
Name Name of the job type.
Params
operationName Name of the Quick-Deploy operation.
deviceId Device ID indicates the Chassis ID.
rootCredential Root user password.
networkTypeV4 Indicates if the IPv4 is static or dynamic.
protocolTypeV4 Indicates whether IPv4 protocol is selected.
subnetMaskV4 IPv4 Subnetwork mask associated with the configuration.
Applicable when static IPv4 is selected.
gatewayV4 IPv4 gateway IP associated with the configuration. Applicable
when static IPv4 is selected.
networkTypeV6 Indicates if the IPv6 is static or dynamic.
protocolTypeV6 Indicates whether IPv6 protocol is selected.
prefixLength Used for IPv6 subnet mask. Applicable when static IPv6 is
selected.
gatewayV6 IPv6 gateway IP associated with the configuration. Applicable
when static IPv6 is selected.
SlotId=<slot_id> Indicates the slot where the settings are applied if slot
selected is True.
Example:
SlotSelected=true;SlotType=3000;IPV4Addres
s=10.27.0.1;IPV6Address=ax0
APIs specific to OpenManage Enterprise – Modular Edition 529
