Users Guide

Successfully created certificate file /home/admin/cert2.pem and key
Supported
releases
10.4.3.0 or later
crypto cert install
Installs a host certificate and private key on the switch. A host certificate may be trusted from a CA or self-signed.
Syntax
crypto cert install cert-file cert-path key-file {key-path | private} [password
passphrase] [fips]
Parameters
• cert-file cert-path — Enter the local path to where the downloaded certificate is stored. You can
enter a full path or a relative path; for example, home://s4048-001-cert.pem or usb://s4048-001-
cert.pem or flash://certs/s4810-001-request.crt.
• key-file {key-path | private} — Enter the local path to retrieve the downloaded or locally
generated private key. Specify a key-path to install the key from a local directory. Enter private to install
the key from a local hidden location. After the certificate is successfully installed, the private key is deleted
from the specified
key-path location and copied to the hidden location.
• password passphrase — (Optional) Enter the password used to decrypt the private key if it was
generated using a password.
• fips — (Optional) Install the certificate-key pair as FIPS-compliant. Enter fips to install a certificate-key
pair that a FIPS-aware application, such as RADIUS over TLS, uses. If you do not enter
fips, the certificate-
key pair is stored as a non-FIPS compliant pair.
Default Not configured
Command mode EXEC
Usage information Before using the crypto cert install command, copy a CA-signed certificate to the home directory on the
switch using a secure connection, such as HTTPS, SCP, or SFTP, and (optionally) the private key. To delete a
trusted certificate, use the crypto cert delete command.
A successful installation of a trusted certificate requires that:
• The downloaded certificate is correctly formatted.
• The downloaded certificate’s public key corresponds to the private key.
You can assign an installed certificate-key pair to a security profile by entering the file name of the certificate
without an extension.
It is possible to store a certificate in either FIPS mode or non-FIPS mode on the switch, but not in both modes,
using the crypto cert install command and the optional fips option. You must ensure that certificates
installed in FIPS mode are compliant with the FIPS 140-2 standard.
Example
OS10# crypto cert install cert-file home://Dell_host1_CA1.pem key-file
home://Dell_host1_CA1.key
Processing certificate ...
Certificate and keys were successfully installed as "Dell_host1_CA1.pem"
that may be used in a security profile. CN = Dell_host1_CA1.
Supported
releases
10.4.3.0 or later
crypto crl delete
Deletes a Certificate Revocation List file in the trust store on the switch.
Syntax
crypto crl delete crl-filename
Parameters
• crl-filename — Enter a CRL filename with the .pem extension as displayed under Manually
installed CRLs in show crypto crl output.
Default Not configured
980 Security
