RADIUS authentication
To configure a RADIUS server for authentication, enter the server IP address or host name, and the key used to authenticate the OS10
switch on a RADIUS host. You can enter the authentication key in plain text or encrypted format. You can change the User Datagram
Protocol (UDP) port number on the server.
• Configure a RADIUS authentication server in CONFIGURATION mode. By default, a RADIUS server uses UDP port 1812.
radius-server host {hostname | ip-address} key {0 authentication-key | 9 authentication-
key | authentication-key} [auth-port port-number]
To configure more than one RADIUS server, re-enter the radius-server host command multiple times. If you configure multiple
RADIUS servers, OS10 attempts to connect in the order you configured them. An OS10 switch connects with the configured RADIUS
servers one at a time, until a RADIUS server responds with an accept or reject response. The switch tries to connect with a server for the
configured number of retransmit retries and timeout period.
Configure global settings for the timeout and retransmit attempts allowed on RADIUS servers. By default, OS10 supports three RADIUS
authentication attempts and times out after five seconds. No source interface is configured. The default VRF instance is used to contact
RADIUS servers.
NOTE: You cannot configure both a non-default VRF instance and a source interface at the same time for RADIUS
authentication.
NOTE: A RADIUS server configured with a host name is not supported on a non-default VRF.
• Configure the number of times OS10 retransmits a RADIUS authentication request in CONFIGURATION mode, from 0 to 100 retries;
the default is 3.
radius-server retransmit retries
• Configure the timeout period used to wait for an authentication response from a RADIUS server in CONFIGURATION mode, from 0 to
1000 seconds; the default is 5.
radius-server timeout seconds
• (Optional) Specify an interface whose IP address is used as the source IP address for user authentication with RADIUS servers in
CONFIGURATION mode. By default, no source interface is configured. OS10 selects the source IP address of any interface from
which a packet is sent to a RADIUS server.
An interface may have two IPv4 addresses and multiple IPv6 addresses. The selected OS10 source interface matches the version of
the RADIUS server IP address: IPv4 or IPv6.
• For an IPv4 RADIUS server, the primary IPv4 address is used.
• For an IPv6 server, any of the global IPv6 addresses configured on the interface are used.
• If no address of the same IP version as the RADIUS server is configured, RADIUS authentication is performed with no source
interface, using the IP address of the management interface. The management IP address serves as the RADIUS network access
server (NAS) IP address on the switch.
ip radius source-interface interface
On the RADIUS server, you must update the configured IP routes using the Linux command line so that the source interface routes
match the NAS IP route.
If OS10 uses a RADIUS server VRF instance, a RADIUS server source interface is not supported and cannot be configured.
• (Optional) By default, the switch uses the default VRF instance to communicate with RADIUS servers. You can optionally configure a
non-default or the management VRF instance for RADIUS authentication in CONFIGURATION mode.
radius-server vrf management
radius-server vrf vrf-name
Configure RADIUS server
OS10(config)# radius-server host 1.2.4.5 key secret1
OS10(config)# radius-server retransmit 10
OS10(config)# radius-server timeout 10
OS10(config)# ip radius source-interface mgmt 1/1/1
