192.168.1.4 vlan2001 00:22:52/00:01:41 v2 4294967295 / DR S
192.168.1.3 vlan2001 00:20:33/00:01:41 v2 4294967290 / S
192.168.1.2 vlan2001 00:23:50/00:01:41 v2 100000 / S
10.192.168.5 vlan1251 00:22:37/00:01:39 v2 1 / DR S
The show ip pim summary command displays the PIM summary.
AG4# show ip pim summary
Entries in PIM-TIB/MFC: 140/80
Active Modes:
PIM-SM
Interface summary:
8 active PIM interfaces
0 passive PIM interfaces
20 active PIM neighbor
TIB Summary:
20/20 (*,G) entries in PIM-TIB/MFC
60/60 (S,G) entries in PIM-TIB/MFC
60/0 (S,G,Rpt) entries in PIM-TIB/MFC
2 RP
3 sources
0 Register states
Message Summary:
389/0 Joins/Prunes sent/received
0/0 Candidate-RP advertisements sent/received
687/1944 BSR messages sent/received
0 Null Register messages received
0/0 Register-stop messages sent/received
Data path event summary:
22 last-hop switchover messages received
120/67 pim-assert messages sent/received
0/0 register messages sent/received
VLT Multicast summary:
0(*,G) synced entries in MFC
0(S,G) synced entries in MFC
0(S,G,Rpt) synced entries in MFC
The show ip pim tib command displays the PIM tree information base (TIB).
AG4# show ip pim tib
PIM Multicast Routing Table
Flags: S - Sparse, C - Connected, L - Local, P - Pruned,
R - RP-bit set, F - Register Flag, T - SPT-bit set, J - Join SPT,
K - Ack-Pending state
Timers: Uptime/Expires
Interface state: Interface, next-Hop, State/Mode
(*, 225.1.0.0), uptime 01:40:17, expires 00:00:58, RP 10.1.100.6, flags: SCJ
Incoming interface: vlan1251, RPF neighbor 10.192.168.5
Outgoing interface list:
vlan2001 Forward/Sparse 01:40:17/Never
vlan2002 Forward/Sparse 01:40:09/Never
vlan2003 Forward/Sparse 01:40:04/Never
vlan2004 Forward/Sparse 01:40:04/Never
vlan2005 Forward/Sparse 01:40:04/Never
(192.168.1.201, 225.1.0.0), uptime 01:27:01, expires 00:00:30, flags: CTP
Incoming interface: vlan2001, RPF neighbor 0.0.0.0
Outgoing interface list:
