Forward Address: 0.0.0.0
External Route Tag: 0
Supported
Releases
10.2.0E or later
show ip ospf database opaque-area
Displays information about the opaque-area Type 10 LSA.
Syntax
show ip ospf [process-id] [vrf vrf-name] database opaque-area
Parameters
• process-id — (Optional) Displays the opaque-area Type 10 information for an OSPF process ID. If you do
not enter a process ID, this command applies only to the first OSPF process.
• vrf vrf-name — (Optional) Displays the opaque-area Type 10 information for an OSPF process ID
corresponding to a VRF.
Default Not configured
Command Mode EXEC
Usage Information
• LS Age — Displays the LS age.
• Options — Displays the optional capabilities available on the router.
• LS Type — Displays the LS type.
• Link State ID — Identifies the router ID.
• Advertising Router — Identifies the advertising router’s ID.
• LS Seq Number — Identifies the LS sequence number. This identifies old or duplicate LSAs.
• Checksum — Displays the Fletcher checksum of an LSA’s complete contents.
• Length — Displays the LSA length in bytes.
• Opaque Type — Identifies the Opaque type field, the first 8 bits of the LS ID.
• Opaque ID — Identifies the Opaque type-specific ID, the remaining 24 bits of the LS ID.
Example
OS10# show ip ospf database opague-area
OSPF Router with ID (1.1.1.1) (Process ID 100)
Type-10 Area Local Opaque (Area 0.0.0.1)
LS age: 3600
Options: (No TOS-Capability, No DC)
LS type: Type-10 Area Local Opaque
Link State ID: 8.1.1.2
Advertising Router: 2.2.2.2
LS Seq Number: 0x80000008
Checksum: 0x83B8
Length: 28
Opaque Type: 8
Opaque ID: 65794
!!
!
Supported
Releases
10.2.0E or later
show ip ospf database opaque-as
Displays information about the opaque-as Type 11 LSAs.
Syntax
show ip ospf [process-id] opaque—as
Parameters process-id — (Optional) Displays opaque-as Type 11 LSA information for a specified OSPF process ID. If you
do not enter a process ID, this command applies only to the first OSPF process.
Default Not configured
Command Mode EXEC
