clear ip bgp flap-statistics
Clears all or specific IPv4 or IPv6 flap counts of prefixes.
Syntax
clear ip bgp [vrf vrf-name] [ipv4–address | ipv6–address] flap-statistics
[ipv4–prefix | ipv6–prefix]
Parameters
vrf vrf-name — (OPTIONAL) Enter vrf then the name of the VRF to clear flap statistics information.
ipv4–address — (Optional) Enter an IPv4 address to clear the flap counts of the prefixes learned from the
given peer.
ipv6–address — (Optional) Enter an IPv6 address to clear the flap counts.
ipv4–prefix — (Optional) Enter an IPv4 prefix to clear the flap counts of the given prefix.
ipv6–prefix — (Optional) Enter an IPv6 prefix to clear the flap counts of the given prefix.
Default Not configured
Command Mode EXEC
Usage Information None
Example (All
Prefixes)
OS10# clear ip bgp flap-statistics
Example (IPv4)
OS10# clear ip bgp 1.1.15.4 flap-statistics
Example (Given
Prefix)
OS10# clear ip bgp flap-statistics 1.1.15.0/24
Supported
Releases
10.3.0E or later
connection-retry-timer
Configures the timer to retry the connection to BGP neighbor or peer group.
Syntax
connection-retry-timer retry-timer-value
Parameters retry-timer-value — Enter the time interval in seconds, ranging from 10 to 65535.
Defaults 60 seconds
Command Modes
CONFIG-ROUTER-NEIGHBOR
CONFIG-ROUTER-TEMPLATE
Usage Information The no version of this command resets the timer to default value..
Example
OS10(config-router-neighbor)# connection-retry-timer 1000
OS10(config-router-template)# connection-retry-timer 100
Supported
Releases
10.3.0E or later
confederation
Configures an identifier for a BGP confederation.
Syntax
confederation {identifier as-num | peers as-number}
Parameters
identifier as-num —Enter an AS number, from 0 to 65535 for 2 bytes, 1 to 4294967295 for 4 bytes,
or 0.1 to 65535.65535 for dotted format.
peers as-number—Enter an AS number for peers in the BGP confederation, from 1 to 4294967295.
Default Not configured
Command Mode ROUTER-BGP
550 Layer 3
