Users Guide

Command Mode MONITOR-SESSION
Usage Information The no version of this command enables the monitoring session.
Example
OS10(config)# monitor session 1
OS10(conf-mon-local-1)# no shut
OS10(config)# monitor session 5 type rpm-source
OS10(conf-mon-rpm-source-5)# no shut
OS10(config)# monitor session 10 type erpm-source
OS10(conf-mon-erpm-source-10)# no shut
Supported
Releases
10.2.0E or later
source
Configures a source for port monitoring. The monitoring session can be: local, RPM, or ERPM.
Syntax
source interface interface-type {both | rx | tx}
Parameters
• interface-type — Enter the interface type:
• ethernet node/slot/port[:subport] — Enter the Ethernet interface information as the
monitored source.
• port-channel id-number — Enter the port-channel interface number as the monitored source,
from 1 to 128.
• vlan vlan-id —Enter the VLAN identifier as the monitored source, from 1 to 4093.
• both — Monitor both receiving and transmitting packets. This option is not supported on VLAN interfaces.
• rx — Monitor only received packets.
• tx — Monitor only transmitted packets. This option is not supported on VLAN interfaces.
Default Not configured
Command Mode MONITOR-SESSION
Usage Information
Example
OS10(config)# monitor session 1
OS10(conf-mon-local-1)# source interface ethernet 1/1/7 rx
OS10(config)# monitor session 5 type rpm-source
OS10(conf-mon-rpm-source-5)# source interface ethernet 1/1/10 rx
OS10(config)# monitor session 10 type erpm-source
OS10(conf-mon-erpm-source-10)# source interface ethernet 1/1/5 rx
Supported
Releases
10.2.0E or later
source-ip
Configures the source, destination, and protocol type of the monitored port for an ERPM monitoring session.
Syntax
source-ip source ip-address destination-ip destination ip-address [gre-protocol
protocol-value]
Parameters
• source ip-address — Enter the source IP address.
• destination ip-address — Enter the destination IP address.
• protocol-value — Enter the GRE protocol value, from 1 to 65535, default: 35006.
Default Not configured
472 Layer 2
