spanning-tree rstp hello-time
Sets the time interval between generation and transmission of RSTP BPDUs.
Syntax
spanning-tree rstp hello-time seconds
Parameters seconds — Enter a hello-time interval value in seconds, from 1 to 10.
Default 2 seconds
Command Mode CONFIGURATION
Usage Information Dell EMC recommends increasing the hello-time for large configurations, especially configurations with multiple
ports.
Example
OS10(config)# spanning-tree rstp hello-time 5
Supported
Releases
10.2.0E or later
spanning-tree rstp mac-flush-threshold
Sets the flush indication threshold value on the RSTP instance.
Syntax
spanning-tree rstp mac-flush-threshold threshold-value
Parameters threshold-value—Enter the threshold value for the number of flushes, from 0 to 65535. The default value is
65535.
Default Not configured
Command Mode CONFIGURATION
Usage Information The threshold value indicates the number of flush indications to go before the flush interval timer is triggered.
When flush indication threshold is set to the default value and the flush interval is set to a non-default value,
flushing occurs during the first flush indication trigger. When the flush indication threshold value is non-default (n)
and flush interval value is non-default, port-based flushing is triggered until the threshold (n) is reached. Once the
threshold is reached, the MAC flush timer starts. On timer expiry, the system triggers instance-based flushing.
When the timer is running, all port-and-instance-based flushing is suppressed. The no form of the command sets
the flush indication threshold to its default value.
Example
OS10(config)# spanning-tree rstp mac-flush-threshold 255
Supported
Releases
10.4.0E(R1) or later
spanning-tree rstp max-age
Configures the time period the bridge maintains configuration information before refreshing the information by recomputing the RSTP
topology.
Syntax
max-age seconds
Parameters seconds — Enter a maximum age value in seconds, from 6 to 40.
Default 20 seconds
Command Mode CONFIGURATION
Usage Information None
Example
OS10(config)# spanning-tree rstp max-age 10
Supported
Releases
10.2.0E or later
