Advertise virtual management IP address in management address TLV
You can enable the system to select a single IP address in a VLT pair, using the lldp management-addr-tlv {ipv4 | ipv6}
virtual-ip command globally or on a specific interface. LLDP advertises the elected virtual IP address in the management address
TLV.
To enable the service to send the virtual management IP address in the management address TLV:
• Enable the service to send the virtual IP address in the management address TLV using lldp management-addr-tlv ipv4
virtual-ip in CONFIGURATION mode.
When enabled in CONFIGURATION mode, the configuration applies globally and the system advertises the elected IP address in the
management address TLV.
• Enable the service to send the virtual IP address in the management address TLV using lldp management-addr-tlv ipv4
virtual-ip in INTERFACE mode.
When enabled in INTERFACE mode, the configuration applies on the specific interface and the system advertises the elected IP
address in the management address TLV.
MX9116-B1(config)#lldp management-addr-tlv ipv4 virtual-ip
MX9116-B1(config-if-eth1/1/6)#lldp management-addr-tlv ipv4 virtual-ip
LLDP commands
clear lldp counters
Clears LLDP and LLDP-MED transmit, receive, and discard statistics from all physical interfaces.
Syntax
clear lldp counters
Parameters None
Default Not configured
Command Mode EXEC
Usage Information The counter default value resets to zero for all physical interfaces.
Example
OS10# clear lldp counters
Supported
Releases
10.2.0E or later
clear lldp table
Clears LLDP neighbor information for all interfaces.
Syntax
clear lldp table
Parameters None
Default Not configured
Command Mode EXEC
Usage Information Neighbor information clears on all interfaces.
Example
OS10# clear lldp table
Supported
Releases
10.2.0E or later
