Users Guide

5 vlan5
6 vlan6
7 vlan7
8 vlan8
9 vlan9
Maximum size of LLDP PDU: 1500
Current LLDP PDU Size: 386
LLDP PDU Truncated(Too many TLV's): false
LLDP MED Capabilities:
Supported:
LLDP-MED Capabilities,
Network Policy,
Inventory Management
Current:
LLDP-MED Capabilities,
Network Policy
LLDP MED Device Type: Network connectivity
Network policy advertisement
LLDP-MED is enabled on all interfaces by default. Configure OS10 to advertise LLDP-MED TLVs from configured interfaces. Define LLDP-
MED network policies before applying the policies to an interface. Attach only one network policy per interface.
• Define an LLDP-MED network-policy in INTERFACE mode.
lldp-med network-policy {add | remove} number
• add — Attach the network policy to an interface.
• remove — Remove the network policy from an interface.
• number — Enter a network policy index number, from 1 to 32.
Configure advertise LLDP-MED network policies
OS10(conf-if-eth1/1/5)# lldp-med network-policy add 1
Fast start repeat count
Fast start repeat count enables a network-connectivity device to advertise itself at a faster rate for a limited amount of time. The fast
start timer starts when a network-connectivity device receives the first LLDP frame from a newly detected endpoint.
When an LLDP-MED endpoint is newly detected or connected to the network, the lldp-med fast-start-repeat-count
command enables the network to quickly detect the endpoint. The LLDP-MED fast start repeat count specifies the number of LLDP
packets that are sent during the LLDP-MED fast start period. By default, the device sends three packets per interval. The number of
packets that are sent during activation ranges from 1 to10.
Rapid availability is crucial for applications such as emergency call service location (E911).
• Enable fast start repeat count which is the number of packets that are sent during activation in CONFIGURATION mode, from 1 to 10,
default 3.
lldp-med fast-start-repeat-count number
Configure fast start repeat count
OS10(config)# lldp med fast-start-repeat-count 5
View LLDP configuration
• View the LLDP configuration in EXEC mode.
show running-configuration
