show lacp port channel
Displays information about LACP port channels.
Syntax
show lacp port-channel [interface port-channel channel-number]
Parameters
• interface port channel — (Optional) Enter the interface port-channel.
• channel-number — (Optional) Enter the port channel number for the LACP neighbor (1 to 128).
Default Not configured
Command Mode EXEC
Usage Information All channel groups display if you do not enter the channel-number parameter.
Example
OS10# show lacp port-channel 1
Port-channel 1 admin up, oper up, mode lacp
Actor System ID: Priority 32768, Address 90:b1:1c:f4:9b:8a
Partner System ID: Priority 32768, Address 00:01:e8:8a:fd:9e
Actor Admin Key 1, Oper Key 1, Partner Oper Key 1
LACP LAG ID 1 is an aggregatable link
A-Active LACP, B-Passive LACP, C-Short Timeout, D-Long Timeout
E-Aggregatable Link, F-Individual Link, G-IN_SYNC, H-OUT_OF_SYNC,
I-Collection enabled, J-Collection disabled, K-Distribution enabled,
L-Distribution disabled, M-Partner Defaulted, N-Partner Non-defaulted,
O-Receiver is in expired state, P-Receiver is not in expired state
Port ethernet1/1/29 is Enabled, LACP is enabled and mode is lacp
Actor Admin: State BCFHJKNO Key 1 Priority 32768
Oper: State BDEGIKNO Key 1 Priority 32768
Partner Admin: State BCEGIKNP Key 0 Priority 0
Oper: State BDEGIKMO Key 1 Priority 32768
Supported
Releases
10.2.0E or later
show lacp system-identifier
Displays the LACP system identifier for a device.
Syntax
show lacp system-identifier
Parameters None
Default Not configured
Command Mode EXEC
Usage Information The LACP system ID is a combination of the configurable LACP system priority value and the MAC address. Each
system that runs LACP has an LACP system priority value. Configure a value between 1 and 65535. The default
value is 32768. LACP uses the system priority with the MAC address to form the system ID and uses the system
priority during negotiation with other devices. A higher system priority value means a lower priority. The system ID
is different for each device.
Example
OS10# show lacp system-identifier
Actor System ID: Priority 32768, Address 90:b1:1c:f4:9b:8a
Supported
Releases
10.2.0E or later
Link Layer Discovery Protocol
Link layer discovery protocol (LLDP) enables network devices on a local area network (LAN) to advertise its identity and capabilities and
learn the capabilities from adjacent LAN devices.
• By default, LLDP is enabled on the interfaces.
