Users Guide

Command Mode INTERFACE
Usage Information The no version of this command resets the maximum bundle size to the default value.
Example
OS10(conf-if-po-10)# lacp max-bundle 10
Supported
Releases
10.2.0E or later
Lacp port-priority
Sets the priority for the physical interfaces for LACP.
Syntax
lacp port-priority priority
Parameters priority — Enter the priority for the physical interfaces (0 to 65535).
Default 32768
Command Mode INTERFACE
Usage Information LACP uses the port priority with the port number to create the port identifier. The port priority decides which
ports are put into Standby mode when there is a hardware limitation that prevents all compatible ports from
aggregating, or when you have more than eight ports configured for the channel group. When setting the priority,
a higher number means a lower priority. The no version of this command returns the port priority to the default
value.
Example
OS10(conf-range-eth1/1/7-1/1/8)# lacp port-priority 32768
Supported
Releases
10.2.0E or later
lacp rate
Sets the rate at which LACP sends control packets.
Syntax
lacp rate {fast | normal}
Parameters
• fast — Enter the fast rate of 1 second.
• normal — Enter the default rate of 30 seconds.
Default 30 seconds
Command Mode INTERFACE
Usage Information Change the LACP timer rate to modify the duration of the LACP timeout. The no version of this command resets
the rate to the default value.
Example
OS10(conf-range-eth1/1/7-1/1/8)# lacp rate fast
Supported
Releases
10.2.0E or later
lacp system-priority
Sets the system priority of the device for LACP.
Parameters
priority — Enter the priority value for physical interfaces (0 to 65535).
Default 32768
Command Mode CONFIGURATION
Usage Information Each device that runs LACP has an LACP system priority value. LACP uses the system priority with the MAC
address to form the system ID and also during negotiation with other systems. The system ID is unique for each
device. The no version of this command resets the system priority to the default value.
Layer 2 383
