Up Time : 1 day 00:48:58
-- Unit 1 --
Status : up
System Identifier : 1
Down Reason : unknown
Digital Optical Monitoring : disable
System Location LED : off
Required Type : S4148F
Current Type : S4148F
Hardware Revision : X01
Software Version : 10.5.0.0
Physical Ports : 48x10GbE, 2x40GbE, 4x100GbE
BIOS : 3.33.0.0-3
System CPLD : 0.4
Master CPLD : 0.10
Slave CPLD : 0.7
Supported
Releases
10.4.3.0 or later
show unit-provision
Displays the unit ID and service tag of the Fabric Expanders attached to a Fabric Switching Engine.
Syntax
show unit-provision
Syntax
show unit-provision
Parameters None
Command Mode EXEC
Usage Information If the Fabric Switching Engine is in Full Switch mode, you must manually configure the unit ID of an attached
Fabric Expander. For more information, see Virtual ports. Use the show unit-provision command to display
the assigned and unassigned unit IDs, and service tag provision name values. Use the unit-provision
command to configure the Fabric Expander with an unassigned unit ID and provision name.
Example
OS10# show unit-provision
Node ID | Unit ID | Provision Name | Discovered Name | State |
--------+---------+----------------+-----------------+-------|
1 | 71 | | | |
1 | 72 | | | |
1 | 73 | | | |
1 | 74 | | | |
1 | 75 | | | |
1 | 76 | | | |
1 | 77 | | | |
1 | 78 | 403RPK2 | 403RPK2 | up |
1 | 79 | | | |
1 | 80 | | | |
1 | 81 | | | |
1 | 82 | | | |
Supported
Releases
10.4.0E(R3S) or later
show vlan
Displays the current VLAN configuration.
Syntax
show vlan [vlan-id]
Parameters vlan-id — (Optional) Enter a VLAN ID, from 1 to 4093.
Default Not configured
