Users Guide

Ethernet 1/1/32 unassigned NO unset up down
Management 1/1/1 10.16.153.226/24 YES manual up up
Vlan 1 unassigned NO unset up down
Vlan 10 unassigned NO unset up down
Vlan 20 unassigned NO unset up down
Vlan 30 unassigned NO unset up down
View VLAN configuration
OS10# show vlan
Codes: * - Default VLAN, M - Management VLAN, R - Remote Port Mirroring VLANs,
@ – Attached to Virtual Network
Q: A - Access (Untagged), T - Tagged
NUM Status Description Q Ports
1 Inactive A Eth1/1/1,1/1/6-1/1/32
10 Inactive
20 Inactive
22 Inactive
23 Active A Eth1/1/2
24 Inactive
25 Inactive
26 Inactive
27 Inactive
28 Inactive
29 Inactive
30 Inactive
Digital optical monitoring
The digital optical monitoring (DOM) feature monitors the digital optical media for temperature, voltage, bias, transmission power (Tx),
and reception power (Rx). This feature also generates event logs, alarms, and traps for any fluctuations, when configured thresholds are
reached.
There are four threshold levels for each of the DOM categories—temperature, voltage, bias, transmission power, and reception power as
summarized in the following table:
• High
• High warning
• Low
• Low warning
The OS10 DOM subsystem periodically monitors the optical transceivers for temperature, voltage, bias, transmission power and reception
power changes and generate event logs, alarms, and traps when their respective values cross the predefined thresholds.
Table 26. DOM Alarms
Alarm Category Alarm Name Traps Generated? Severity Level
Temperature Temperature high Y Major
Temperature high
warning
N Minor
Temperature low Y Major
Temperature low
warning
N Minor
Voltage Voltage high Y Major
Voltage high warning N Minor
Voltage low Y Major
Voltage low warning N Minor
Bias Bias high Y Major
Bias high warning N Minor
Bias low Y Major
