Users Guide

Configure SNMP engineID
OS10(config)# snmp-server engineID local 80:00:02:b8:04:61:62:63
Display SNMP engineID
OS10# show snmp engineID local
Local default SNMP engineID: 0x800002a2036c2b59fbd8a0
Configure SNMP views
Configure a read-only, read-write, or notify view of the MIB tree structure in the SNMP agent on the switch.
The oid-tree value specifies the OID in the MIB tree hierarchy at which a view starts. Enter included or excluded to include or
exclude the rest of the sub-tree MIB contents in the view. If necessary, re-enter the command to exclude tree entries in the included
content.
snmp-server view view-name oid-tree [included | excluded]
Configure read-only view
OS10(config)# snmp-server view readonly 1.3.6.1.2.1.31.1.1.1.6 included
Configure read-write view
OS10(config)# snmp-server view rwView 1.3.6.1.2.1.31.1.1.1.6 included
OS10(config)# snmp-server view rwView 1.3.6.1.2.1.31.0.0.0.0 excluded
Display SNMP views
OS10# show snmp view
view name : readview
OID : 1.3.6.5
excluded : True
Configure SNMP groups
Configure an SNMP group with the views allowed for the members of the group. Specify the read-only, read-write, and/or notification
access to the SNMP agent.
The security model corresponds to the SNMP version that users use to send and receive SNMP messages. The security level configures
SNMPv3 user authentication and privacy settings:
• auth — Authenticate users in SNMP messages.
• noauth — Do not authenticate users or encrypt SNMP messages; send messages in plain text.
• priv — Authenticate users and encrypt/decrypt SNMP messages.
Enter an ACL to limit user access so that only messages from and to ACL-allowed users are received and sent from the SNMP agent on
the switch.
snmp-server group group-name {v1 | v2c | v3 security-level} [access acl-name]
[read view-name] [write view-name] [notify view-name]
To configure a view of the MIB tree on the SNMP agent, use the snmp-server view command.
To configure an SNMPv3 user's authentication and privacy settings, use the snmp-server user command.
To display the configured SNMP groups, use the show snmp group command.
Configure SNMPv1 or v2c group
OS10(config)# snmp-server group v2group 2c read readview notify GetsSets
Configure SNMPv3 group
OS10(config)# snmp-server group v3group 3 priv read readview write writeview notify alltraps
System management
139
