Users Guide

Example
OS10(config)# switch-operating-mode Full-Switch
Supported
releases
10.4.3.0 or later
gnmi-security-profile
Set the security profile for the gNMI agent.
Syntax
gnmi-security-profile profile-name
Parameters profile-name — Enter the name of the security profile to be associated with the gNMI agent.
Default Not configured
Command mode CONFIGURATION
Usage information
Before establishing a connection to the gNMI agent, set a valid application-specific security profile for the gNMI
agent. Also, configure a FQDN or an IP address for entry to the SmartFabric Director server, assign client and CA
certificates, and assign the syatem Admin privileges to the user role that is used to access the agent. The security
profile is configured on the switch using the
crypto security-profile command.
Example
os10(config)# gnmi-security-profile gnmi_sec_profile
Supported
releases
10.5.0.1 or later
show switch-operating-mode
View the operating mode of the switch.
Syntax
show switch-operating-mode
Parameters None
Default Not configured
Command mode EXEC
Usage information Some OS10 switches operate in both Full Switch and SmartFabric modes. For PowerEdge MX Ethernet I/O
modules, see Operating modes. This command is updated to display the SmartFabric Director operating mode
starting in release 10.5.0.1.
Example
OS10# show switch-operating-mode
Switch-Operating-Mode : SmartFabric Director Mode
Supported
releases
10.4.0E(R3S) or later
show sfd status
Displays the status corresponding to the SmartFabric Director.
Syntax
show sfd status
Default Display the controller IP address and the port status of the SmartFabric Director.
Command mode EXEC
Usage information None.
Examples
OS10# show sfd status
Controller IP Port Status
SmartFabric Director 129
