Users Guide

• Private Subnet Prefix
• Private Prefix Length
• Global Subnet Prefix
• Global Subnet Length
• Client Control VLAN
• Client Management VLAN
3. Click OK.
NOTE: After you click OK, all the switches in the network fabric reload to apply the fabric setting changes.
Fabric operations and life cycle management
Dell EMC Open Manage Network Integration (OMNI) is an efficient REST API-based plugin, integrated with VMware's vCenter. The plugin
enables vCenter to easily deploy and manage a large virtual network of VMs and physical underlay on a VxRail HCI stack. Using OMNI, you
can do day two operations and management of the hyper-converged fabric.
You can do the common lifecycle operations using OMNI.
• Upgrade OS10 software in a network fabric
• Replace a switch in a fabric
For more information about OMNI, see VMware Integration for VxRail Fabric Automation SmartFabric User Guide.
SmartFabric commands
You can enter SmartFabric Services show commands from the OS10 CLI to view SmartFabric configuration information, including:
• SmartFabric cluster role (master or backup) and cluster member information
• SmartFabric personality
• SmartFabric status, nodes, and network profiles
• SmartFabric uplinks
smartfabric l3fabric enable
Enables the SmartFabric Services on the switches and creates a network fabric in a Clos-based spine-and-leaf architecture.
Syntax
smartfabric l3fabric enable role {LEAF [vlti ethernet node/slot/port] | SPINE}
Parameters role — Enter the role of the switch in Layer 3 fabric:
• LEAF — Specify the role as LEAF for top of rack switches and specify the VLTi ports that interconnect the
leaf switches.
• SPINE — Specify the role as SPINE for the switch that connects the leaf switches.
Default None
Command Mode CONFIGURATION
Usage Information
After you enable the L3 fabric and set a role, a network fabric is created automatically with default fabric settings.
After executing the command, the system prompts for confirmation and reboot with changed personality. If you
type Yes, the switch reloads with the configured SmartFabric personality. For supported platforms, see
SmartFabric Services for leaf and spine.
The no smartfabric l3fabric command disables the L3 fabric personality. After you disable the L3 fabric
in the switch, the system prompts for confirmation.
Example (Spine)
OS10(config)# smartfabric l3fabric enable role SPINE
Reboot to change the personality? [yes/no]: yes
Example (Leaf)
OS10(config)# smartfabric l3fabric enable role LEAF vlti
ethernet 1/1/4-1/1/5
SmartFabric Services 119
