Users Guide

Example
OS10(config)# route-map bgp
OS10(conf-route-map)# match extcommunity extcommlist1 exact-match
Supported
Releases
10.3.0E or later
match interface
Configures a filter to match routes whose next-hop is the configured interface.
Syntax
match interface interface
Parameters interface — Interface type:
• ethernet node/slot/port[:subport] — Enter the Ethernet interface information as the next-hop
interface.
• port-channel id-number — Enter the port-channel number as the next-hop interface, from 1 to 128.
• vlan vlan-id —Enter the VLAN number as the next-hop interface, from 1 to 4093.
Default Not configured
Command Mode ROUTE-MAP
Usage Information The no version of this command deletes the match.
Example
OS10(conf-route-map)# match interface ethernet 1/1/1
OS10(conf-if-eth1/1/1)#
Supported
Releases
10.2.0E or later
match ip address
Configures a filter to match routes based on IP addresses specified in IP prefix lists.
Syntax
match ip address {prefix-list prefix-list-name | access-list-name}
Parameters
• prefix-list-name — Enter the name of the configured prefix list. A maximum of 140 characters.
• access-list-name — Enter the name of the configured access list.
Default Not configured
Command Mode ROUTE-MAP
Usage Information The no version of this command deletes a match.
Example
OS10(config)# route-map bgp
OS10(conf-route-map)# match ip address prefix-list test10
Supported
Releases
10.3.0E or later
match ip next-hop
Configures a filter to match based on the next-hop IP addresses specified in IP prefix lists.
Syntax
match ip next-hop prefix-list prefix-list
Parameters prefix-list — Enter the name of the configured prefix list. A maximum of 140 characters.
Default Not configured
Command Mode ROUTE-MAP
1080 Access Control Lists
