• fin — (Optional) Set the bit as finish—no more data from sender.
• psh — (Optional) Set the bit as push.
• rst — (Optional) Set the bit as reset.
• syn — (Optional) Set the bit as synchronize.
• urg — (Optional) Set the bit set as urgent.
• capture — (Optional) Capture packets the filter processes.
• count — (Optional) Count packets the filter processes.
• byte — (Optional) Count bytes the filter processes.
• dscp value — (Optional) Deny a packet based on the DSCP values, from 0 to 63.
• fragment — (Optional) Use ACLs to control packet fragments.
• log — (Optional) Enables ACL logging. Information about packets that match an ACL rule are logged.
• operator — (Optional) Enter a logical operator to match the packets on the specified port number. The
following options are available:
• eq — Equal to
• gt — Greater than
• lt — Lesser than
• neq — Not equal to
• range — Range of ports, including the specified port numbers.
Default Not configured
Command Mode IPV6-ACL
Usage Information OS10 cannot count both packets and bytes; when you use the count byte options, only bytes increment. The
no version of this command removes the filter.
Example
OS10(config)# ipv6 access-list ipv6test
OS10(conf-ipv6-acl)# deny udp any any capture session 1
Supported
Releases
10.2.0E or later
description
Configures an ACL description.
Syntax
description text
Parameters text — Enter the description text string. A maximum of 80 characters.
Default Disabled
Command Modes IPV4-ACL, IPV6-ACL, MAC-ACL
Usage Information The no version of this command deletes the ACL description.
Example
OS10(conf-ipv4-acl)# description ipacltest
Supported
Releases
10.2.0E or later
ip access-group
Configures an IPv4 access group.
Syntax
ip access-group access-list-name {in | out}
Parameters
• access-list-name — Enter the name of an IPv4 access list. A maximum of 140 characters.
• in — Apply the ACL to incoming traffic.
