seq 5 permit icmp any any capture session 1 count (0 packets)
seq 10 permit ip 102.1.1.0/24 any capture session 1 count bytes (0 bytes)
seq 15 deny udp any any capture session 2 count bytes (0 bytes)
seq 20 deny tcp any any capture session 3 count bytes (0 bytes)
View monitor sessions
OS10(conf-if-eth1/1/1)# show monitor session all
S.Id Source Destination Dir SrcIP DstIP DSCP TTL State Reason
----------------------------------------------------------------------------
1 ethernet1/1/1 ethernet1/1/4 both N/A N/A N/A N/A true Is UP
View ACL table utilization report
The show acl-table-usage detail command shows the ingress and egress ACL tables for the various features and their
utilization.
The hardware pool area displays the ingress application groups (pools), the features mapped to each of these groups, and the amount of
used and free space available in each of the pools. The amount of space required to store a single ACL rule in a pool depends on the
keywidth of the TCAM slice.
The service pool displays the amount of used and free space for each of the features. The number of ACL rules configured for a feature is
displayed in the configured rules column. The number of used rows depends on the number of ports the configured rules are applied on.
Under
Allocated pools, you can view the percentage of dedicated space reserved for a particular feature or the phrase Shared if you have
not reserved space for each of the features individually, against the total number of pools allocated for the application group. In the
example given below, the SYSTEM_FLOW feature has 15 percentage of space reserved in ingress app-group-1 with a pool count of 1,
which is represented by 15:1.
OS10# show acl-table-usage detail
Ingress ACL utilization
Hardware Pools
----------------------------------------------------------------------------------------------
---------
Pool ID App(s) Used rows Free
rows Max rows
----------------------------------------------------------------------------------------------
---------
0 SYSTEM_FLOW 49
975 1024
1 SYSTEM_FLOW 49
975 1024
2 USER_IPV4_ACL 3
1021 1024
3 USER_L2_ACL 2
1022 1024
4 USER_IPV6_ACL 2
510 512
5 USER_IPV6_ACL 2
510 512
6 FCOE 55
457 512
7 FCOE 55
457 512
8 ISCSI_SNOOPING 12
500 512
9 FREE 0
512 512
10 PBR_V6 1
511 512
11 PBR_V6 1
511 512
----------------------------------------------------------------------------------------------
---------
Service Pools
----------------------------------------------------------------------------------------------
---------
App Allocated pools App group Configured rules Used rows Free
rows Max rows
----------------------------------------------------------------------------------------------
---------
