OS10 (config-openflow-switch)# controller ipv6 2025::1 port 6633
OS10 (config-openflow-switch)# controller ipv6 2025::12 port 6633
where IP or IPv6 address is of the controller and port 6633 is for OpenFlow communication.
5. Enter the no shutdown command to enable the logical switch instance.
OS10 (config-openflow-switch) no shutdown
Establish TLS connection
• Generate the switch and controller certificates from a server that supports public-key infrastructure (PKI). You need the following
certificates:
• Controller certificate
• Switch certificate
• Private key file to verify the switch certificate
• The certificates and private key files must be in the Privacy-Enhanced Mail (PEM) format.
For certificate-based authentication, you must establish a TLS connection between the switch and the controller before you configure
OpenFlow on the switch. The following procedure explains how to install the controller and switch certificates on the OS10 switch. Refer
to the controller documentation for information on how to install the certificates on the controller.
NOTE: This procedure is optional. Use this procedure if you want to configure certificate-based authentication between
the switch and the controller.
1. Log in to the OS10 switch with administrator credentials.
2. Enter the following command to copy the certificates to the OS10 switch.
In the following commands, the destination path and the destination file name on the OS10 switch, for example, config://../
openflow/cacert.pem, remain the same in your deployment. Ensure that you enter the destination path and destination file
names as specified in the following example:
OS10# copy scp://username:password@server-ip/full-path-to-the-certificates/controller-
cert.pem config://../openflow/cacert.pem
OS10# copy scp://username:password@server-ip/full-path-to-the-certificates/switch-cert.pem
config://../openflow/sc-cert.pem
OS10# copy scp://
username:password@server-ip/full-path-to-the-certificates/switch-
privkey.pem config://../openflow/sc-privkey.pem
where server-ip refers to the server where you have stored the certificates, and username and password refers to the credentials you
need to access the server with the certificates.
3. Perform the steps described in the Configure OpenFlow protocol on the switch topic to configure OpenFlow.
OpenFlow commands
controller
Configures an OpenFlow controller that the logical switch instance connects to.
Syntax
controller {ipv4 ipv4-address| ipv6 ipv6-address [port port-number] [security
{none|tls}]
Parameters
• ipv4 ipv4-address—Enter ipv4, then the IP address of the controller.
• ipv6 ipv6-address—Enter ipv6, then the IPv6 address of the controller.
• port port-number—Enter the keyword, then the port number, from 1 to 65,535. The default port is
6653.
• security {none|tls}—Specify the type of connection. The default is security none. The TCP
connection is used.
Default TCP. The default port number is 6653.
Command Mode OPENFLOW SWITCH CONFIGURATION
