POST_SCRIPT_FILE="http://50.0.0.1/no_post_script.py"
################### DO NOT MODIFY THE LINES BELOW #######################
sudo os10_ztd_start.sh "$IMG_FILE" "$CLI_CONFIG_FILE" "$POST_SCRIPT_FILE"
######################## **END** ###############################
ZTD CLI batch file
Create a CLI batch file that ZTD downloads and executes to configure a switch. The ZTD CLI batch file consists of two sections: PRE-
CONFIG and POST-CONFIG.
When you enter the PRE-CONFIG and POST-CONFIG lines, you must enter a hash tag (#), followed by a space before the text PRE-
CONFIG or POST-CONFIG. If the PRE-CONFIG section has no commands, do not leave a blank line between # PRE-CONFIG and #
POST-CONFIG; for example:
# PRE-CONFIG
# POST-CONFIG
Hostname VxRail-fabric-LEAF-1
!
lldp enable
!
spanning-tree mode rstp
spanning-tree rstp priority 0
...
ZTD executes the PRE-CONFIG commands first using the currently running OS10 image, not the OS10 image specified in the provisioning
script. ZTD saves the PRE-CONFIG settings to the startup configuration.
If PRE-CONFIG commands are present, ZTD reloads the switch before executing the commands in the POST-CONFIG section. Enter
OS10 configuration commands that require a switch reload, such as switch-port-profile, in the PRE-CONFIG section. If ZTD
installs a new OS10 image (
IMG_FILE), the new image is activated after the reload.
ZTD then executes the POST-CONFIG commands and saves the new settings in the startup configuration. No additional switch reload is
performed. Enter
POST_CONFIG commands with the exact syntax displayed in show running-configuration output.
Example
# PRE-CONFIG
switch-port-profile 1/1 profile-2
# POST-CONFIG
snmp-server community public ro
snmp-server contact NOC@dell.com
snmp-server location delltechworld
!
clock timezone GMT 0 0
!
hostname LEAF-1
!
ip domain-list networks.dell.com
ip name-server 8.8.8.8 1.1.1.1
!
ntp server 132.163.96.5 key 1 prefer
ntp server 129.6.15.32
!
!
logging server 10.22.0.99
Post-ZTD script
As a general guideline, use a post-ZTD script to perform any additional functions required to configure and operate the switch. In the ZTD
provisioning script, specify the post-ZTD script path for the
POST_SCRIPT_FILE variable. You can use a script to notify an
orchestration server that the ZTD configuration is complete. The server can then configure additional settings on the switch.
