54 Dell EMC PowerEdge MX SmartFabric Configuration and Troubleshooting Guide
Note: Any configuration not completed by the OME-M console is lost when switching between IOM operating
modes.
6.8 Module replacement process in SmartFabric
Dell EMC PowerEdge MX platform gives you an option to replace the I/O Modules in a SmartFabric mode in
case of any errors or failures. MX9116n FSE and MX5108n can be replaced with another same type of I/O
Module. In case of errors or failures, replace the old IOM with the new IOM using Linux command.
For Module Replacement process, follow the steps:
1. Physically replace the IOM.
2. Identify the master IOM in a fabric.
3. Execute the process of module replacement from the master IOM using the module replacement
command.
6.8.1 Physically replace the IOM
Follow the below instructions to physically replace IOM:
• Identify the faulty IOM to replace. Disconnect the cables connected to faulty IOM.
• Insert the new IOM in the same slot as the failed IOM. The IOM should be in SmartFabric and must
be up and running.
• The model of the IOM should be same.
• The new IOM should have the same version of SmartFabric OS10 as the old IOM.
• Confirm if the new IOM has been recognized by OME-M before proceeding further.
6.8.2 Identify the master IOM in a fabric
To identify the master IOM in the fabric, run sfs_master_details.py command on the Linux shell prompt
the IOM. To run the above command, follow the instructions below:
1. Login to the Linux shell
OS10# system bash
admin@MX9116n-A1#:~$
2. Go to the bin directory on SmartFabric OS10 by running cd /opt/dell/os10/bin command. This
directory will have all the python scripts to run for the module replacement process.
• Identify the master IOM by running sfs_master_details.py.
admin@MX9116N-A1:/opt/dell/os10/bin$sfs_master_details.py
• If you run the command on master IOM, the output will be I am the Master. If you run the
command on other member IOMs it will return the IPv6 address of master IOM.
For Example:
The console displays the following output on Master IOM:
admin@MX9116N-A1:/opt/dell/os10/bin$sfs_master_details.py
I am the Master
