13 Dell EMC PowerEdge MX SmartFabric Configuration and Troubleshooting Guide
3. Fabric automation
• Physical topology compliance
• Server networking managed via templates
• Automated QoS assignment per VLAN
• Automated storage networking
4. Failure remediation
• Dynamically adjusts bandwidth across all inter-switch links in the event of a link failure
• Automatically detects fabric misconfigurations or link level failure conditions
• Automatically heals the fabric on failure condition removal
Note: In SmartFabric mode, MX series switches operate entirely as a Layer 2 network fabric. Layer 3 protocols
are not supported.
When operating in SmartFabric mode, access to certain CLI commands is restricted to SmartFabric OS10
show commands and can run the following subset of CLI configuration commands:
• clock – Configure clock parameters
• end – Exit to the EXEC mode
• exit – Exit from the current mode
• fc alias – Set Fiber Channel name
• fc zone – Set Fiber Channel zone name
• fc zoneset – Set Fiber Channel zoneset name
• help – Display available commands
• hostname – Set the system hostname
• host-description – Define the description for the host
• interface – Configure or select an interface
• ip nameserver – Configure nameserver
• ip ssh server – Configure SSH server
• ip telnet server – Configure Telnet server
• login concurrent-session – Start concurrent session and login
• login statistics – Enable timeframe for the login session
• logging – Configure system logging
• management route – Configure the IPV4/IPv6 management route
• no – Delete or disable commands in configuration mode
• ntp – Configure the network time protocol
• snmp-server – Configure the SNMP server
• tacacs-server – Configure the TACACS server
• username – Create or modify user credentials
• spanning-tree commands:
- disable – Disable spanning tree globally
- mac-flush-timer – Set the time used to flush MAC address entries
- mode – Enable a spanning-tree mode, such as RSTP
