12 Dell EMC PowerEdge MX SmartFabric Configuration and Troubleshooting Guide
• show switch-operating-mode – displays the current operating mode (SmartFabric or
Full Switch) of a supported switch
• show discovered-expanders – displays the MX7116n FEMs attached to the MX9116n
FSEs
• show unit-provision – displays or configures the unit ID and service tag of a MX7116n
FEM attached to a MX9116n FSE
Note: For more information, see the SmartFabric OS10 User Guide for PowerEdge MX I/O Modules on the
Support for Dell EMC Networking MX9116n - Manuals and documents and Support for Dell EMC Networking
MX5108- Manuals and documents web pages.
2.2.1 Full Switch mode
In Full Switch mode, all SmartFabric OS10 features and functions supported by the hardware are available to
the user. In other words, the switch operates the same way as any other SmartFabric OS10 switch.
Configuration is primarily done using the CLI, however, the following items can be configured or managed
using the OME-M GUI:
1. Initial switch deployment: Configure hostname, password, SNMP, NTP, etc.
2. Set ports administratively up or down, configure MTU
3. Monitor health, logs, alerts, and events
4. Update the SmartFabric OS10 software
5. View physical topology
6. Switch power management
Full Switch mode is typically used when a desired feature or function is not available when operating in
SmartFabric mode. For more information about Dell EMC SmartFabric OS10 operations, see Dell EMC
Networking OS Info Hub.
2.2.2 SmartFabric mode
A SmartFabric is a logical entity that consists of a collection of physical resources, such as servers and
switches, and logical resources such as networks, templates, and uplinks. The OpenManage Enterprise –
Modular (OME-M) console provides a method to manage these resources as a single unit.
In the PowerEdge M1000e and FX2 platforms, I/O Aggregation (IOA) was implemented to simplify the
process to connect blade servers to upstream networks, so server administrators and generalists could
manage uplinks, downlinks, and VLAN assignments without needing to be fluent with the CLI.
SmartFabric Services mode builds on this IOA functionality providing:
1. Data center modernization
• I/O Aggregation
• Plug-and-play fabric deployment
• Single interface to manage all switches in the fabric
2. Lifecycle management
• Fabric-wide SmartFabric OS10 updates
• Automated or user enforced roll back to last well-known state
